D.I. Flanged Puddle Pipe

D.I. Flanged Puddle Pipe Specification

Tolerance
10 Millimeter (mm)

Product Type
Flange

Material
Iron

Connection
Other

Shape
Round

Standard
BS

Surface Treatment
Zinc Coating

Outer Diameter
80 MM to 1200 MM Millimeter (mm)

Section Shape
Round

Length
100 MM to 5500 MM Millimeter (mm)

Thickness
5 MM to 13MM Millimeter (mm)

Color
Black, Blue

Warranty
1 Year

D.I. Flanged Puddle Pipe Trade Information

Minimum Order Quantity
100 Meters

FOB Port
Howrah

Supply Ability
500 Meters Per Week

Delivery Time
1 Week

Packaging Details
Customized Packaging in Transport By Trucks & Trailers .

Main Domestic Market
Tripura, Himachal Pradesh, Manipur, Andaman and Nicobar Islands, Pondicherry, Uttarakhand, Daman and Diu, Dadra and Nagar Haveli, Lakshadweep, South India, Chandigarh, East India, West India, Assam, Arunachal Pradesh, Goa, Jammu and Kashmir, Jharkhand, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Punjab, Rajasthan, Sikkim, Tamil Nadu, West Bengal, Nagaland, Bihar, Uttar Pradesh, Haryana, Delhi, Gujarat, Karnataka, North India, Telangana, Andhra Pradesh, Kerala, Central India, Odisha, Chhattisgarh, All India

Certifications
ISO 9001: 2015 NSIC certified

About D.I. Flanged Puddle Pipe

D.I. Flanged Puddle Pipe manufactured and supplied by us is designed for extreme pressure flow systems due to their high capability to withstand high water columns. It is fabricated by using advanced production technologies that make it free from manufacturing flaws and provide high structural accuracy. The double flange design of the offered D.I. Flanged Puddle Pipe makes it easier to install it with the help of mechanical fasteners that ensures high durability and robustness.

Features::

CI Pipes manufactured as per ASTM specification.
Leading manufacturers of manipulated tubes.

Technical Specifications

	Nominal Diameter	Pipe Diameter
PN	DN	O.D	D	PCD	a	b	L	D		B.C
PN10	80	98	200	160	19.0	16.0	70	19	8	166
	100	118	220	180	19.0	16.0	70	19	8	187
	150	170	285	240	19.0	16.0	75	23	8	240
	200	222	340	295	20.0	17.0	75	23	8	293
	250	274	400	350	22.0	19.0	90	23	12	346
	300	326	455	400	24.5	20.5	90	23	12	410
	350	378	505	460	24.5	20.5	100	23	16	469
	400	429	565	515	24.5	20.5	100	28	16	521
	450	480	615	565	25.5	21.5	110	28	20	573
	500	532	670	620	26.5	22.5	110	28	20	626
	600	635	780	725	30.0	25.0	115	31	20	730
	700	738	895	840	32.5	27.5	115	31	24	837
	800	842	1015	950	35.0	30.0	115	34	24	943
	900	945	1115	1050	37.5	32.5	115	34	28	1047
	1000	1048	1230	1160	40.0	35.0	115	37	28	1159
	1100	1152	1340	1270	42.5	37.5	115	37	32	1264
	1200	1255	1455	1380	45.0	40.0	115	40	32	1368
PN16	80	98	200	160	19.0	16.0	70	19	8	166
	100	118	220	180	19.0	16.0	70	19	8	187
	150	170	285	240	19.0	16.0	75	23	8	240
	200	222	340	295	20.0	17.0	75	23	12	293
	250	274	400	355	22.0	19.0	90	28	12	346
	300	326	455	410	24.5	20.5	90	28	12	410
	350	378	520	470	26.5	22.5	100	28	16	469
	400	429	580	525	28.0	24.0	100	31	16	521
	450	480	640	585	30.0	26.0	110	31	20	573
	500	532	715	650	31.5	27.5	110	34	20	626

Superior Material Quality

Crafted from ductile iron and protected with zinc coating, the flanged puddle pipe delivers excellent longevity and resistance against harsh environmental conditions. The round section shape enhances flow and structural integrity, making it suitable for demanding water infrastructure projects.

Flexible Dimensions and Usage

Offering thicknesses ranging from 5 mm to 13 mm and lengths up to 5500 mm, this product accommodates diverse installation requirements. The broad diameter range ensures suitability for different pipe networks, while BS certification guarantees reliable performance and safety standards.

Warranty and Support

Each D.I. Flanged Puddle Pipe is covered by a one-year warranty, ensuring peace of mind for buyers. As trusted suppliers in India, we provide comprehensive pre- and post-sales support to ensure seamless procurement and installation experiences.

FAQs of D.I. Flanged Puddle Pipe:

Q: How can the D.I. Flanged Puddle Pipe be installed in water management systems?

A: This pipe is designed for easy integration into water-related infrastructure projects. Its flanged ends enable secure bolted connections, and the round section shape facilitates smooth flow, making installation straightforward for contractors and engineers.

Q: What is the manufacturing process for the D.I. Flanged Puddle Pipe?

A: The pipe is manufactured using high-quality ductile iron, shaped into a round section according to BS standards. After fabrication, each piece undergoes zinc coating for enhanced corrosion resistance and is checked for dimensional tolerance before packing.

Q: When is it recommended to use the D.I. Flanged Puddle Pipe?

A: It is ideal for use in both underground and aboveground water supply systems, especially where surface protection and robust mechanical strength are necessary, such as in urban and industrial waterworks projects.

Q: Where is this pipe typically utilized in infrastructural projects?

A: These pipes are commonly installed in municipal water supply networks, sewage treatment plants, irrigation systems, and industrial fluid conveyance where secure, leak-proof connectivity is essential.

Q: What surface treatment ensures the durability of the D.I. Flanged Puddle Pipe?

A: A zinc coating is applied to each pipe during production. This protective layer defends the iron against corrosion, extending product lifecycle and maintaining performance even in harsh environments.

Q: How does the warranty benefit customers?

A: With a one-year warranty, users are assured of product reliability and post-purchase support. In case of manufacturing defects, the warranty allows for prompt replacement or repair, reducing downtime and maintenance costs.
