Flange on Double Socket Tee

Flange on Double Socket Tee Specification

Temperature Range
-10C to 80C

Yield Strength
Minimum 300 MPa

Connection Type
Push-fit Socket and Flanged Connection

Bend Radius
Not Applicable (Rigid Tee Fitting)

Tensile Strength
Minimum 420 MPa (Ductile Iron)

Flexibility
Rigid

Coating Type
Epoxy / Bitumen

Sealing Type
Rubber Gasket (EPDM/NBR)

Diameter
DN 80 to DN 600

Thread Type
Not Applicable (Socket and Flange Connection)

Tolerance
1% or per standard specification

Product Type
Flange on Double Socket Tee

Material
Ductile Iron / Cast Iron

Connection
Double Socket End with Flanged Outlet

Shape
T-shaped (Tee with Two Sockets and a Flanged Outlet)

Standard
IS 9523 / EN 545 / BS 4772

Surface Treatment
Fusion Bonded Epoxy Coated / Bitumen Painted

Outer Diameter
80 mm to 600 mm (as per size option)

Section Shape
Round Socket, Flanged Branch

Length
250 mm to 700 mm (varies by diameter)

Thickness
8 mm to 25 mm (varies by size)

Color
Black / Blue / Red (customizable)

Usage
Pipe Branch Connection in Water Supply/Distribution Systems

Rated Pressure
PN 10 / PN 16 / PN 25

Material Grade
Grade 400/12 (Ductile Iron), IS:210 FG260 (Cast Iron)

Application
Water Supply, Sewage, Irrigation, Industrial Pipeline

Flange on Double Socket Tee Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Months

About Flange on Double Socket Tee

Flange on double socket tee is designed to make an 87.5 degree angle in the connection between the main vertical pipe and the lateral soil/waste pipe. readily available with a door for cleaning. It divides or combines fluid flow. In addition to this, our offering can reorient a pipe run, connect pipes of various diameters, or do both. The said product also transfers two-fluid combinations and come in a variety of materials, sizes, and finishes. Flange on double socket tee is made up of galvanized iron and can resist corrosion and provides enduring strength. It is used to unite two pipes at a 90-degree angle.

Reliable Tee Solution for Modern Pipelines

Our Double Socket Tee with Flanged Branch Outlet is engineered to offer exceptional mechanical strength and watertight integrity in demanding pipeline systems. Suitable for both horizontal and vertical installation, this fitting efficiently connects branch lines to main pipes and is compatible with water supply, sewage, and industrial applications. Enhanced with a corrosion-resistant epoxy or bitumen coating, it stands up to harsh environments and ensures prolonged service life.

Engineered for Leak-Free Performance

Featuring premium EPDM or NBR rubber gaskets as the socket seal, this tee fitting guarantees a secure and leak-free joint under varying pressure conditions. Its robust construction allows for a nominal operating pressure up to PN 25 and a temperature range from -10C to 80C. Each tee is hydrostatically tested up to 25 bar, delivering peace of mind for operators and installers in all sectors.

FAQs of Flange on Double Socket Tee:

Q: How is the Flange on Double Socket Tee with Branch Outlet installed in pipeline networks?

A: The Double Socket Tee with Flanged Branch Outlet is designed for horizontal or vertical installation. It connects to existing pipelines using a push-fit socket at both ends and a flanged outlet for branch connections. Installation involves properly aligning the fitting, inserting pipe spigots into the sockets with EPDM or NBR gaskets for sealing, and securing the flange with bolts to the mating pipe or equipment.

Q: What applications and environments are suitable for this tee fitting?

A: This tee fitting is ideal for a wide range of applications, including water supply and distribution systems, sewage networks, irrigation infrastructure, and various industrial pipelines. The corrosion-resistant coating and robust material selection make it suitable for both above-ground and buried installations in municipal, agricultural, and industrial environments.

Q: What advantages does fusion bonded epoxy coating provide?

A: Fusion bonded epoxy coating significantly enhances corrosion resistance, extending the lifespan of the fitting even in aggressive soil or water conditions. It creates a durable, impermeable barrier that protects the ductile or cast iron substrate from chemical and environmental attack, minimizing maintenance costs and operational downtime.

Q: Which standards and certifications does the product comply with?

A: The Flange on Double Socket Tee with Branch Outlet conforms to leading industry standards, including EN 545, ISO 2531, IS 9523, and BS 4772. These certifications verify that the product meets stringent requirements for material quality, dimensional accuracy, and hydrostatic pressure performance.

Q: When should EPDM or NBR rubber gaskets be selected for socket sealing?

A: EPDM rubber gaskets are recommended for water and most general-purpose applications due to their excellent resistance to heat, ozone, and chemicals. NBR rubber gaskets are suitable for systems conveying oils or hydrocarbons, offering superior resistance to oil-based fluids and certain chemicals. The choice depends on the specific media being transported.

Q: What benefits do users gain from selecting this tee fitting?

A: Users benefit from robust mechanical strength, reliable watertight sealing, versatile installation options, and long-term resistance to corrosion. The standardized design ensures compatibility with various pipe sizes and network layouts, streamlining system expansions or modifications with minimal effort.

Q: Where is the product available and who can supply it?

A: This product is available through exporters, manufacturers, suppliers, and wholesalers based in India, with the capability to serve both domestic and international customers. Customizable options in color, coating, and size ensure suitability for diverse project requirements.
